CERTIFICATIONS / RATINGS

• UL Listed
• UL924
• NFPA 101 Life Safety Code
• NEC
• OSHA
• See Specification Sheet For Complete Listing

KEY FEATURES AND BENEFITS

• Sealed and gasketed weatherproof lamp heads with high performance chrome-plated metalized reflector and tempered glass lenses for optimal light distribution.
• Long lasting efficient ultra bright white LED lamp heads.
• 1.875W (15 LEDs x 0.125) per head.

DOWNLOADS

SPECIFICATIONS

ELECTRICAL
• Dual 120/277 voltage.
• Charge rate/power “ON” LED indicator light and push-to-test switch for mandated code compliance testing.
• 9.6V long life, maintenance-free, rechargeable NiCd battery.
• Internal solid-state transfer switch automatically connects the internal battery to LED lamp heads for minimum 90-minute emergency illumination.
• Fully automatic solid-state, two rate charger initiates battery charging to recharge a discharged battery in 24 hours.
• Remote capacity of 3.7W standard in operating temperatures of 0°C – 50°C.

HOUSING
• Corrosion-resistant 5VA flame retardant UV-stabilized polycarbonate in gray or black finish.
• Sealed and gasketed housing with hinged cover.
• Sealed test switch.

MOUNTING
• External mounting brackets for simplified wall mounting.
• Knockout for conduit applications.

OPTIONS
• CEC: Certified to CEC under Title 20 Regulations.

WARRANTY / LISTING
• Five year warranty on all electronics and housing. Battery prorated for five years.
• Meets UL924, NFPA 101 Life Safety Code, NEC, OSHA,
• Local and State Codes.
• UL Listed for wet locations (-20°C to 50°C)

See specification sheet for product ordering selection, mounting options, weights and dimensions.
