Narrow Band Yellow Light (590nm) – Ultraviolet Free / No UV
CERTIFICATIONS / RATINGS
UL STANDARDS
• UL 844 – Hazardous Locations │ UL1598
NEC and CEC
• Class I, Div 1 – Groups B ,C, D
• IP67
• NEMA 6
• RoHS Compliant
• CSA C22.2 137.0
• CE
• See Specification Sheet For Complete Listing
KEY FEATURES AND BENEFITS
• Narrow band yellow light (590nm / blocks UV wavelengths under 500nm) designed for use in semiconductor manufacturing, laboratories, health care facilities, pharmaceutical labs, and other applications where UV light would be damaging.
• Available in 2 window or 3 window configurations.
• Heavy duty aluminum housing.
DOWNLOADS
SPECIFICATIONS
| Voltage |
120 VAC, 277 VAC |
| Wattage |
60W / 80W / 90W / 100W / 110W / 120W |
| Color Temp |
1800 Kelvin (Yellow) / 590nm |
| Housing |
Aluminum alloy |
| Color |
Gray |
| Lens |
Tempered glass |
| Lifetime |
60,000 hrs L70 |
| Beam Angles |
X-116° / Y-114° |
| Ambient Temperature |
-20°C (-4°F) to 40°C (104°F) |
| T-Rating |
T5 |
| Power Factor |
cos ≥ 0.9 |
| Protection |
IP67 / NEMA 6 |
| Entrance Thread |
1 x 3/4” |
| Warranty |
5 Year Limited Warranty |
LUMENS
| 60W |
80W |
90W |
100W |
110W |
120W |
| 3,600 lm |
4,800 lm |
5,400 lm |
6,000 lm |
6,600 lm |
7,200 lm |
See specification sheet for product ordering selection, mounting options, weights and dimensions.
Narrow Band Yellow Light (590nm) – Ultraviolet Free / No UV
CERTIFICATIONS / RATINGS
UL STANDARDS
• UL 844 – Hazardous Locations │ UL1598 | UL8750
NEC and CEC
• Class I, Div 2 – Groups A, B ,C, D
• IP67
• NEMA 6
• RoHS Compliant
• CSA C22.2 137-18
• CSA C22.2 250.0
• CSA C22.2 250.13
• CE
• IEC / IECEx
• See Specification Sheet For Complete Listing
KEY FEATURES AND BENEFITS
• Narrow band yellow light (590nm / blocks UV wavelengths under 500nm) designed for use in semiconductor manufacturing, laboratories, health care facilities, pharmaceutical labs, and other applications where UV light would be damaging.
• Available in 2ft or 4ft lengths.
• Heavy duty aluminum housing.
• Wall, ceiling or street light mounting options available.
DOWNLOADS
SPECIFICATIONS
| Voltage |
120 VAC, 277 VAC |
| Wattage |
20W / 40W / 60W / 80W / 120W / 160W |
| Color Temp |
1800 Kelvin (Yellow) / 590nm |
| Housing |
Aluminum alloy |
| Color |
Gray |
| Lens |
Tempered glass |
| Lifetime |
60,000 hrs L70 |
| Beam Angles |
X-116° / Y-114° |
| Ambient Temperature |
-40°C (-40°F) to 45°C (113°F) |
| T-Rating |
T3C |
| Power Factor |
cos ≥ 0.9 |
| Protection |
IP67 / NEMA 6 |
| Warranty |
5 Year Limited Warranty |
LUMENS
| 20W |
40W |
60W |
80W |
120W |
160W |
| 1,700 lm |
3,150 lm |
4900 lm |
6,550 lm |
9,800 lm |
13,000 lm |
See specification sheet for product ordering selection, mounting options, weights and dimensions.
Narrow Band Yellow Light (590nm) – Ultraviolet Free / No UV
CERTIFICATIONS / RATINGS
UL STANDARDS
• UL 844 – Hazardous Locations │ UL1598
NEC and CEC
• Class I, Div 1 – Groups C, D
• Class II, Div 1 – Groups E, F, G
• IP67
• NEMA 6
• RoHS Compliant
• CSA C22.2 137-18
• CSA C22.2 250.0
• CE
• IEC / IECEx
• See Specification Sheet For Complete Listing
KEY FEATURES AND BENEFITS
• Narrow band yellow light (590nm / blocks UV wavelengths under 500nm) designed for use in semiconductor manufacturing, laboratories, health care facilities, pharmaceutical labs, and other applications where UV light would be damaging.
• Available as a single tube or dual tube configuration in 2ft or 4ft lengths.
• Heavy duty aluminum housing.
• Wall, ceiling or pendant mounting options available.
• Includes protective wire guard.
DOWNLOADS
SPECIFICATIONS
| Voltage |
120-277 VAC |
| Wattage |
10W / 20W / 40W |
| Color Temp |
1800 Kelvin (Yellow)* / 590nm |
| Housing |
Aluminum Alloy |
| Color |
Gray |
| Lens |
Glass Tubes |
| Lifetime |
60,000 hrs L70 |
| Beam Angles |
110° |
| Ambient Temperature |
-20°C (-4°F) to 40°C (104°F) |
| T-Rating |
T6 |
| Power Factor |
cos ≥ 0.9 |
| Protection |
IP67 / NEMA 6 |
| Warranty |
5 Year Limited Warranty |
LUMENS
| 1X2 10W |
1X4 20W |
2X2 20W |
2X4 40W |
| 450 |
900 |
900 |
1,800 |
See specification sheet for product ordering selection, mounting options, weights and dimensions.
